EM PF FLOOR MNT SYSTEM 512 KVAR 550V

Supplier Description & Specifications:

Power factor systems (automatic) 400/525/550V

For applications with varying capacitor requirements. An automatic reactive controller monitors the network and only switches capacitor banks when required, avoiding potential over or under compensation in a network.

FMS series – Floor standing systems

Complete ready-to-install system comprising following:

• Mains isolator, door interlocking (with early make/late break auxiliary contact)
• Suitably ventilated floor standing enclosure (thermostatically controlled roof mounted exhaust fan)
• High end reactive control relay DCRG 8 (incorporating digital display of all important network parameters)

Able to monitor all three phase voltage and current to providing accurate indication of:

• Internal panel temperature monitoring
• Calendar-clock with backup reserve power
• Current and Voltage Harmonics analysis (up to 31st harmonic)
• Active, Apparent Power as well as Active, Reactive, Apparent Energy monitoring
• Event logging: alarms, setup changes, events etc. (internal memory stores last 250 events)

Expandable with up to 4 expansion modules for:

• additional steps, analog Inputs/Outputs, RS323
• RS485, Ethernet, GPRS/GSM modem communication
